2B9-252 Goodyear Double Convoluted Air Spring 578-92-3-206 Air Bellows air Bags

उत्पाद विवरण:

उत्पत्ति के प्लेस:	गुआंग्डोंग, चीन
ब्रांड नाम:	GUOMAT
प्रमाणन:	ISO/TS16949, ISO9001
मॉडल संख्या:	2बी9252

भुगतान & नौवहन नियमों:

न्यूनतम आदेश मात्रा:	5
मूल्य:	$59.9-69.9/pc
पैकेजिंग विवरण:	मजबूत कार्टन बॉक्स या ग्राहकों की आवश्यकता के अनुसार
प्रसव के समय:	5-8 कार्य दिवस
भुगतान शर्तें:	एल/सी, डी/ए, डी/पी, वेस्टर्न यूनियन
आपूर्ति की क्षमता:	1000 पीसी/सप्ताह

संपर्क करें

विस्तृत उत्पाद विवरण

बेलो टाइप:	डबल सजा हुआ	गुणवत्ता:	100 % परीक्षण किया
फ़क्शन:	सदमा कम करें	बिक्री के बाद सेवा:	12 महीने
प्रकार:	गैस से भरे	शुभवर्ष:	2बी9-252/578-92-3-206
ContiTech:	एफडी 200-25 454	आघात:	3.8 इंच -12.2 इंच
प्रमुखता देना:	Goodyear double convoluted air spring , Suspension air spring air bellows , Air bags with warranty

2B9-252 Goodyear Double Convoluted Air Spring 578-92-3-206 Air Bellows air Bags

Product Overview

The GUOMAT 2B9252 air spring features a high-strength rubber and multi-layered fabric reinforcement structure, specifically designed for truck and trailer suspension systems. It automatically adjusts air pressure according to load, effectively absorbing road impacts, maintaining vehicle height stability, and improving ride comfort and handling. Compared to steel springs, it offers a longer service life and lower maintenance costs, making it a reliable suspension replacement solution.

Compatible Models

This air spring can replace the following models:

GOODYEAR: 2B9-252, 2B 9-252, 2B9 252, 578923206, 578 92 3 206, 578-92-3-206
CONTITECH: 64554, FD200-25 454, FD 200-25 454
FIRESTONE: 6944, W01-358-6944, W01 358 6944

Brand	Part Number
AUTOMANN	ABSP2B12RA-6944
HISTEER	10302
LOAD GUARD	SC2124
SUSPENSIONS INC.	200118
TRIANGLE	4448
TRP	AS69440

Technical Specifications

Mounting Interface: Top Plate: 2 holes/studs; 6.4-inch diameter; 3.38-inch bolt circle diameter.

Bottom Plate: 2 holes/studs; 6.4-inch diameter; aligned parallel to the top plate.

Internal Bumper: Included

Operating Height Range: 3.8 in (min.) to 12.2 in (max.)

Total Stroke: 8.4 in (calculated)

Product Features

The GUOMAT 2B9252 suspension air spring is engineered for heavy-duty truck and trailer suspension systems, providing reliable load support and excellent vibration isolation. Manufactured with premium rubber and multi-ply reinforced fabric, it offers outstanding durability, fatigue resistance, and long service life under demanding operating conditions.

This air spring automatically adjusts internal air pressure according to vehicle load, helping maintain consistent ride height, improved stability, and enhanced driving comfort. Compared with traditional steel springs, the GUOMAT 2B9252 delivers smoother performance, reduced noise and vibration, lower maintenance requirements, and extended service life of tires and suspension components.

Designed for OEM and aftermarket use, the GUOMAT 2B9252 is widely applied in commercial vehicles, trailers, and heavy transport applications, making it a cost-effective and dependable suspension solution.

Direct Replacement Models

The GUOMAT 2B9252 air spring is designed as a direct replacement for the following models:
