2B9-210 Goodyear Double Convoluted Air Spring FD 200-19 362 Contitech Modified Car Air Suspension

उत्पाद विवरण:

उत्पत्ति के प्लेस:	गुआंगज़ौ, चीन
ब्रांड नाम:	GUOMAT
प्रमाणन:	ISO/Ts16949:2009
मॉडल संख्या:	2बी6908

भुगतान & नौवहन नियमों:

न्यूनतम आदेश मात्रा:	6pcs
मूल्य:	$59.9-69.9/pc
पैकेजिंग विवरण:	ग्राहकों की आवश्यकताओं के अनुसार कार्टन पैकेजिंग या पैकेजिंग
प्रसव के समय:	5-8 कार्य दिवस
भुगतान शर्तें:	एल/सी, टी/टी, वेस्टर्न यूनियन
आपूर्ति की क्षमता:	10,000 प्रति सप्ताह

संपर्क करें

विस्तृत उत्पाद विवरण

नाम टाइप करें:	सस्पेंशन एयर स्प्रिंग बैग	वसंत सामग्री:	प्राकृतिक रबर
गुणवत्ता:	100 % परीक्षण किया	गारंटी:	12 महीने
रंग:	काला	शुभवर्ष:	2बी9-210/578-92-3-202
आघात:	3.2 इंच-10.8 इंच	फायरस्टोन:	W01-358-6908
प्रमुखता देना:	Goodyear double convoluted air spring , Contitech modified car air suspension , FD 200-19 air suspension spring

2B9-210 Goodyear Double Convoluted Air Spring FD 200-19 362 Contitech Modified Car Air Suspension

Product Overview

Air springs for modified cars are specialized components used in vehicle suspension systems to enhance driving experience and vehicle performance. They adjust suspension stiffness and height using air pressure, providing greater flexibility and adaptability compared to traditional steel springs.

Key Benefits

Better adaptation to different road conditions
Reduced vibration and impact for improved comfort
Enhanced stability and handling performance
Adjustable ride height for customized appearance
Compatible with automatic or manual adjustment systems

Product Specifications

Brand

GUOMAT

Model Number

2B6908

Material

Rubber and Steel

Warranty

12 Months

Cross-Reference Part Numbers

Manufacturer	Part Numbers
Goodyear	2B9-210 / 2B 9-210 / 2B9 210
Goodyear Bellows	578-92-202 / 578 92 202 / 57892202
Contitech	64511, FD200-19 362 / FD 200-19 362
Firestone	6908, W01-358-6908 / W01 358 6908 / W013586908

Alternative Manufacturer Equivalents

AUTOMANN	ABSP2B12R-6908
TRIANGLE	4362
TRP	AS69080
WATSON&CHALIN	AS-0035

Technical Data

Mounting Holes/Studs

2 on top and bottom plates

Plate Diameter

6.4 inches (both plates)

Bolt Circle Diameter

3.5 inches

Plate Alignment

Bottom plate parallel to top plate

Internal Bumper

Not included

Minimum Height

3.2 inches

Maximum Height

10.8 inches

Total Stroke

7.6 inches

Goodyear Double Convoluted Air Spring Series

Part Number	Top Plate Holes	Bottom Plate Holes	Top Plate Dia.	Bottom Plate Dia.	Collapsed Height	Flexmember
2B9-229	1	1	6.4	6.4	2.9	578-92-3-211
2B9-245	1	1	6.4	6.4	3.8	578-92-3-202
2B9-218	1	2	6.4	6.4	3.5	578-92-3-206
2B9-230	1	2	6.4	6.4	3.8	578-92-3-202
2B9-246	2	1	6.4	6.4	3.8	578-92-3-211
2B12-304	2	1	9	9	3.4	578-92-3-309
2B12-411	2	1	9	9	3.5	578-92-3-309
2B12-412	2	1	9	9	4.2	578-92-3-309
2B9-244	2	2	6.4	6.4	3.8	578-92-3-202
2B9-252	2	2	6.4	6.4	3.8	578-92-3-206
2B9-254	2	2	6.4	6.4	3.8	578-92-3-206
2B9-265	2	2	6.4	6.4	3.8	578-92-3-206
2B9-266	2	2	6.4	6.4	3.8	578-92-3-208
2B12-410	2	2	9	9	3.5	578-92-3-309
2B12-427	2	2	9	9	3.5	578-92-3-309
2B12-432	2	2	9	9	3.5	578-92-3-309
2B12-434	2	2	9	9	3.5	578-92-3-310
2B12-307	2	2	9	9	3.5	578-92-3-305
2B12-313	2	2	9	9	3.5	578-92-3-309
2B12-317	2	2	9	9	3.5	578-92-3-310
