| उत्पत्ति के प्लेस: | गुआंग्डोंग, चीन |
| ब्रांड नाम: | GUOMAT |
| प्रमाणन: | ISO/TS16949:2009 |
| मॉडल संख्या: | 1बी7009 |
| न्यूनतम आदेश मात्रा: | 6pcs |
|---|---|
| मूल्य: | $49.9-59.9/pc |
| पैकेजिंग विवरण: | मजबूत कार्टन बॉक्स या ग्राहकों की जरूरत के रूप में |
| प्रसव के समय: | 2-8 काम के दिन |
| भुगतान शर्तें: | टी/टी, वेस्टर्न यूनियन, एल/सी |
| आपूर्ति की क्षमता: | 1000 पीसी/सप्ताह |
| स्प्रिंग प्रकार: | एकल जटिल प्रकार | गारंटी: | 1 वर्ष |
|---|---|---|---|
| वसंत सामग्री: | धातु + रबर | आवेदन: | औद्योगिक उपकरण अनुप्रयोग के लिए |
| फायरस्टोन: | W01-358-7009 | ContiTech: | एफएस 330-11 468 |
| बफर ब्लॉक: | साथ | वज़न: | 4.6 किग्रा |
| प्रमुखता देना: | Goodyear suspension air bags,industrial air spring rubber bellows,578913301 air spring with warranty |
||
| Top Cover Plate Diameter | 231mm |
| Bottom Cover Plate Diameter | 231mm |
| Gas Hole / Air Inlet | 1/4NPTF |
| Rubber Bellows MAX Diameter | 325mm |
| The Working Stroke | MAX 160mm to MIN 68mm |
| Top Cover Plate Screw (Nut) Tooth | 2×3/8-16UNC |
| Bottom Cover Plate Screw (Nut) Tooth | 2×3/8-16UNC |
| Screw Center Distance of Top Cover Plate | 157.5mm |
| Screw Center Distance of Bottom Cover Plate | 157.5mm |
| Buffer Block | With |
| Manufacturer | Part Numbers |
|---|---|
| Firestone | W01-358-7009, W01 358 7009, W013587009 |
| Contitech | FS330-11 468, FS 330-11 468 |
| Goodyear | 1B12-301, 1B 12-301, 1B12 301 |
| Goodyear Bellows | 578913301, 578 91 3 301, 578-91-3-301 |
| Triange | 6374, 4468 |
| SAF Holland | 90557002AR741 |
| Ridewell | 1003587009C |
| Assembly Height (in.) | Volume@100PSIG (in³) | Pound Force | ||||
|---|---|---|---|---|---|---|
| @20PSIG | @40PSIG | @60PSIG | @80PSIG | @100PSIG | ||
| 5.0 | 394 | 780 | 1,690 | 2,640 | 3,730 | 4,870 |
| 4.0 | 327 | 1,300 | 2,610 | 4,060 | 5,500 | 7,050 |
| 3.0 | 244 | 1,580 | 3,280 | 5,000 | 6,720 | 8,440 |
| Function | Explanation | Risks Without It |
|---|---|---|
| 1. Prevent Structural Impact | Avoids metal-to-metal contact between mounting structures when air spring completely deflates | Deformation of mounting points, bolt shearing, or damage to surrounding equipment |
| 2. Maintain Minimum Safe Height | Supports load after pressure loss, preserving essential clearance for equipment and operation | Sudden drop may snap pneumatic lines or electrical wires, or cause ground contact |
| 3. Limit Over-Extension | Prevents rubber bellows from being over-stretched and torn during rebound conditions | Permanent damage to air spring bellows, rendering it unusable after re-inflation |
| 4. Control Lateral Movement | Provides lateral restraint at travel limit, preventing excessive tilting or misalignment | Equipment may become highly unstable or experience significant misalignment after deflation |
| 5. Provide Failure Warning | Frequent contact indicates insufficient system pressure or chronic leak in air spring system | Problems remain undetected until complete system failure leads to an incident |
