| उत्पत्ति के प्लेस: | गुआंग्डोंग, चीन |
| ब्रांड नाम: | GUOMAT |
| प्रमाणन: | ISO/TS16949:2009 |
| मॉडल संख्या: | 2H250180 |
| न्यूनतम आदेश मात्रा: | 6pcs |
|---|---|
| मूल्य: | $139.9-149.9/pc |
| पैकेजिंग विवरण: | मजबूत कार्टन बॉक्स या ग्राहकों की जरूरत के रूप में |
| प्रसव के समय: | 2-8 काम के दिन |
| भुगतान शर्तें: | एल/सी, टी/टी, वेस्टर्न यूनियन |
| आपूर्ति की क्षमता: | 1000pcs/सप्ताह |
| प्रोडक्ट का नाम: | औद्योगिक एयर स्प्रिंग/एयर बैग/एयर बैलून/एयर लिफ्ट | सामग्री: | उच्च गुणवत्ता वाला रबर |
|---|---|---|---|
| गारंटी: | 12 महीने | ओम: | उपलब्ध |
| क्रॉस नं।: | टोर-प्रेस 245 मॉडल | मानक: | 93740 |
| संयोग: | 2 | जोड़ने वाले छेद: | एम 8 x 1.25 |
| प्रमुखता देना: | Universal Air Lift Bag 245,Double Convoluted Air Spring,Industrial Machine Air Spring |
||
Brand: GUOMAT
Model: 2H250180
Replace Tor-press 245
Replace Standard Code 93740
| Connection | F1 |
| Max.OD | 270 mm |
| Min.Height | 85 mm |
| Max.Height | 245 mm |
| Static Height | 165 mm |
| Effec.Area | 169 cm2 |
| Cap. | 1150 daN |
| Freq. | 127 cicli/1' |
| Stiffness | 12 DaN/mm |
| Threaded Air Hole | - |
| Center Distance of Holes | 145 mm |
| Flange Diameter | 200 mm |
| Connecting Number | 8pcs |
| Bolts or Holes | M8X1.25 |
| Total Travel | 225mm |
| Thrusts Max. | 2680daN |
| Thrusts Min. | 740daN |
| Thrusts in daN Pressures P=0.6 MPa (6 bar) Based On Travel | Travel in mm |
|---|---|
| 2680 | (0) |
| 2620 | (20) |
| 2560 | (40) |
| 2460 | (60) |
| 2320 | (80) |
| 2160 | (100) |
| 1960 | (120) |
| 1760 | (140) |
| 1540 | (160) |
| 1300 | (180) |
| 1060 | (200) |
| 810 | (220) |
Simply put, flange-connected air springs change their internal air pressure by filling and expelling compressed air, thus achieving functions such as height adjustment, load support, and vibration damping/isolation.
Compressed air is filled into the air chamber, increasing the internal pressure. This causes the air chamber to expand, increasing its height and thus lifting the load above it, providing rigid support.
The compressed air is released from the air chamber, decreasing the internal pressure. The air chamber contracts under the weight of the load, lowering its height, and the load decreases accordingly.
After filling with an appropriate amount of air, the system is closed to maintain a constant internal air pressure, thus providing a stable support height and load-bearing capacity.
