| उत्पत्ति के प्लेस: | गुआंगज़ौ, चीन |
| ब्रांड नाम: | GUOMAT |
| प्रमाणन: | ISO/TS16949, ISO9001 |
| मॉडल संख्या: | 1T6032 |
| न्यूनतम आदेश मात्रा: | 5PCS |
|---|---|
| मूल्य: | USD79.9-89.9/PC |
| पैकेजिंग विवरण: | मजबूत कार्टन बॉक्स या ग्राहकों की आवश्यकता के रूप में |
| प्रसव के समय: | 3-7 कार्य दिवस |
| भुगतान शर्तें: | एल/सी, टी/टी, वेस्टर्न यूनियन या अन्य |
| आपूर्ति की क्षमता: | 1000pcs/सप्ताह |
| गुडइयर नं.: | 1R12-432 | सामग्री: | प्राकृतिक रबर |
|---|---|---|---|
| समारोह: | झटका कम करना | प्रकार: | गैस से भरे |
| आवेदन: | ट्रक सस्पेंशन सिस्टम | स्प्रिंग वेट: | 5.833 |
| फायरस्टोन: | W01-358-9875 1T15MT-9 | पिस्टन: | प्लास्टिक |
| प्रमुखता देना: | Goodyear trailer air spring assembly,Truck air suspension replacement bag,1R12-432 air spring with warranty |
||
| Item | Rubber Bellows Truck Air Spring |
|---|---|
| Material | High Quality Rubber |
| Warranty | 12 Months |
| Model No. | 1T 6032 |
| Condition | Brand New |
| Application | Truck / Trailer |
| Function | Reduce Vibration |
| Color | Black |
| Delivery Time | 2-8 working days |
| Maximum Height | 600mm |
|---|---|
| Minimum Height | 200mm |
| Stroke | 400mm |
| Outer Diameter | 270mm |
| Cover Plate Diameter | 231mm |
| Base Diameter | 255mm |
| Piston Height | 140mm |
| Screw | M12x1.75 |
| Air Hole | 1/4NPTF |
| Firestone | Flex Number | Piston | Tape | Bottom Plate Feature | Top Plate Feature | Bottom Plate Dia | Bottom Plate Dia | Collapsed Height |
|---|---|---|---|---|---|---|---|---|
| W01-358-9382 | 1T15M-9 | - | - | - | - | - | - | - |
| W01-358-8866 | 1T15M-9 | - | - | - | - | - | - | - |
| W01-358-9106 | 1T15M-9 | - | - | - | - | - | - | - |
| W01-358-9241 | 1T15M-9 | - | - | - | - | - | - | - |
| W01-358-9102 | 1T15M-9 | - | - | - | - | - | - | - |
| W01-358-9130 | 1T15M-9 | - | - | - | - | - | - | - |
| W01-358-9876 | 1T15M-9 | - | - | - | - | - | - | - |
| W01-358-8856 | 1T15M-9 | 9532 | P | 1 | 1 | 9 | 10.25 | 7.3 |
| W01-358-8855 | 1T15M-9 | 9530 | P | 1 | 4 | 9 | 10.25 | 7.3 |
| W01-358-9101 | 1T15M-9 | - | - | 2 | - | 9 | - | - |
| W01-358-9192 | 1T15M-9 | - | - | 2 | - | 9 | - | - |
| W01-358-9245 | 1T15M-9 | - | - | 2 | - | 9 | - | - |
| W01-358-9346 | 1T15M-9 | - | - | 2 | - | 9 | - | - |
| W01-358-8842 | 1T15M-9 | 9532 | P | 2 | 1 | 9 | 10.25 | 7.9 |
| W01-358-9243 | 1T15M-9 | 9532 | P | 2 | 1 | 9 | 10.25 | 7.4 |
| W01-358-9203 | 1T15M-9 | 9530 | P | 2 | 4 | 9 | 10.3 | 8 |
| W01-358-9238 | 1T15M-9 | 9553 | P | 2 | 4 | 9 | 10.3 | 10 |
| W01-358-9349 | 1T15M-9 | 9553 | P | 2 | 4 | 9 | 10.3 | 10.1 |
| W01-358-9348 | 1T15M-9 | 9553 | P | 2 | 4 | 9 | 10.3 | 10.6 |
| W01-358-8861 | 1T15M-9 | 9530 | P | 2 | 4 | 9 | 10.25 | 7.9 |
| W01-358-9240 | 1T15M-9 | 9553 | P | 2 | 4 | 9 | 10.25 | 9.2 |
| W01-358-9394 | 1T15M-9 | 9553 | P | 2 | 5 | 9 | 10.3 | 9.2 |
| W01-358-9350 | 1T15M-9 | 9553 | P | 2 | 5 | 9 | 10.3 | 9.2 |
| W01-358-8864 | 1T15M-9 | 9531 | P | 3 | 1 | 9 | 8.05 | 7.75 |
| W01-358-8852 | 1T15M-9 | 9532 | P | 3 | 1 | 9 | 10.25 | 6.7 |
| W01-358-9646 | 1T15MBTW-10 | 9532 | P | 2 | 1 | 9 | 10.25 | 7.4 |
| W01-358-9645 | 1T15MBTW-12 | 9540 | P | 2 | 1 | 9 | 10.25 | 9.2 |
| W01-358-9644 | 1T15MBTW-6 | 9532 | P | 2 | 1 | 9 | 10.25 | 7.4 |
| W01-358-8944 | 1T15MW-7 | 9694 | A | 1 | 4 | 9 | 11.06 | 7.3 |
| W01-358-9265 | 1T15MM-9 | 9694 | A | 1 | 4 | 9 | 11.06 | 7.3 |
